Image preview - the first page of the document
>> Download PCZ1206116AE documenatation <<
Text preview - extract from the document
ORDER NO. : PCZ1206116AE
Service Manual
LCD TV
Model No. TX-L32C5E
TX-L32C5ES
TX-L32C5B
TX-LR32C5
TX-LR32U5
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by
electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the product or
products dealt with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These are marked by in the Schematic Diagrams,
Circuit Board Diagrams. Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced with
manufacture's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of manufacturer.
