Image preview - the first page of the document
>> Download TX_L42E6BK documenatation <<Text preview - extract from the document TX-L42E6BK
42" LCD HDTV
SPECIFICATIONS
Dimensions (W x H x D) 957 mm x 619 mm x 217 mm
(With Pedestal)
957 mm x 564 mm x 49 mm
(TV only)
Mass 15.0 kg (With Pedestal)
13.5 kg (TV only)
Power Source AC 220-240 V, 50 / 60 Hz
DIMENSIONS JACKS
Top View Side Panel
Front View Side View
957 36
564
619
Rear Panel
95.6
400
217
Back View
400
400
Note:
To make sure that the LCD TV fits the cabinet properly when a high degree of precision
is required, we recommend that you use the LCD TV itself to make the necessary Specifications are subject to change without notice.
cabinet measurements. Panasonic cannot be responsible for inaccuracies in cabinet Non-metric weights and measurements are
design or manufacture. approximate.
P130321
