Image preview - the first page of the document



>> Download Panasonic_TH-32FS600D_Chassis_KM37_[X] documenatation <<

Text preview - extract from the document

                                                                                                                           ORDER NO. PAVCI1806001




                                                                                                                                       LED TV
                                                                              Model No. TH-32FS600D
                                                                              Chassis: KM37
                                                                              Destination:        INDIA




TABLE OF CONTENTS
                                                                   PAGE                                                                           PAGE
 1 Safety Precautions ----------------------------------------------- 3              5.6. Hotel mode ------------------------------------------------ 11
    1.1. General Guidelines---------------------------------------- 3                  5.6.1. Purpose ------------------------------------------------ 11
      1.1.1. Leakage Current Cold Check ---------------------- 3                      5.6.2. Access command to the Hotel mode setup
      1.1.2. Leakage Current Hot Check (See Figure 1.) ---- 3                                 menu --------------------------------------------------- 11
 2 Warning -------------------------------------------------------------- 4            5.6.3. To exit the Hotel mode setup menu------------- 11
    2.1. Prevention of Electrostatic Discharge (ESD)                                   5.6.4. Explain the Hotel mode setup menu ----------- 11
         to Electrostatically Sensitive (ES) Devices ---------- 4                6 Troubleshooting Guide --------------------------------------- 12
    2.2. About lead free solder (PbF) ---------------------------- 4                 6.1. Check of the IIC bus lines------------------------------ 12
 3 Service Navigation ----------------------------------------------- 5                6.1.1. How to access --------------------------------------- 12
    3.1. Service Hint ------------------------------------------------- 5              6.1.2. Screen display --------------------------------------- 12
 4 Specifications ----------------------------------------------------- 6            6.2. Power LED blinking timing chart --------------------- 12
 5 Service Mode ------------------------------------------------------- 8            6.3. Method of detecting SOS ------------------------------ 13
    5.1. How to enter into Service Mode ----------------------- 8                    6.4. LCD Panel test mode ----------------------------------- 13
      5.1.1. Purpose ------------------------------------------------- 8             6.5. No Power--------------------------------------------------- 14
      5.1.2. Key command ----------------------------------------- 8             7 Disassembly and Assembly Instructions--------------- 15
      5.1.3. How to exit---------------------------------------------- 8
    5.2. Repack ------------------------------------------------------- 9
    5.3. EDID Clock -------------------------------------------------- 9
    5.4. USB HDD Drive Check----------------------------------- 9
    5.5. White Balance Adjustment -----------------------------10
