Image preview - the first page of the document
>> Download Panasonic_NN-GT23HM documenatation <<
Text preview - extract from the document
Microwave Oven
Model No. NN-GT23HM
20L GRILL
Silver
India
s
Power Requirement 230 Volts AC 50 Hz
Microwave 1250W (5.6 A)
Grill 1000 W (4.1 A)
Single phase, 3 wire grounded
Power Output 800 Watts full microwave power (IEC60705)
Microwave Frequency 2,450 MHz
Magnetron 2M219J
Timer 0 ~ 90 min.
Outside Dimensions 443 (W) x340 (D) x 258(H) mm
Cavity Dimensions 306(W) x 308 (D ) x 215(H ) mm
Net Weight 12.3 kg (approx.)
Shipping weight 13.5 kg (approx.)
Specifications subject to change without notice.
