Image preview - the first page of the document



>> Download NN-ST652W documenatation <<

Text preview - extract from the document

                                                                                      Order No. MOD1006319 PE




                                                                                        Microwave Oven
                                                                    Model No. NN-ST652WRUN
                                                                              NN-ST652WRUK


                                                               32L
                                                                   White
                                                                   Brazil




                    s
                                NN-ST652WRUN                                NN-ST652WRUK
Power Requirement       127 Volts AC 60 Hz                           220 Volts AC 60 Hz
                        1,650 Watts (14.0 A)                         1,650 Watts (8.0 A)
                        Single phase, 3 wire grounded                Single phase, 3 wire grounded

Power Output                                   900 Watts full microwave power (IEC60705)
Microwave Frequency                            2,450 MHz
Magnetron                                       2M219J
Timer                                           0 ~ 99 minutes and 50 seconds
Outside Dimensions                              520(W) x 325(H)x416(D) mm
Internal Capacity                               32 Litros
Weight                                          14.2kg (approx.)

                        Specifications subject to change without notice.
