Image preview - the first page of the document
>> Download Panasonic_PT-AE3000EH_[SM] documenatation <<Text preview - extract from the document ORDER NO. VED0810391A3
D10
PT-AE3000U/E PT-AE3000U/E
PT-AE3000EH
Please file and use this manual together with the service manual for Model No. PT-AE3000E
Order No.VED0810389C0.
CONTENTS
1 Points of difference between AE3000E and AE3000EH
1.1. Replacement Parts List
PT-AE3000E (Base Model) PT-AE3000EH
Ref. No. Part Name & Description Remarks
Part No. Pcs Part No. Pcs
MODEL NAME PLATE TBMH203 1 TBMH277 1
MODEL NO. LABEL TBMH204 1 TBMH278 1
1-2 POWER CORD(EUROPE) K2CM3FH00001 1 0
64 BOTTOM COVER TXFKF01QYDZ 1 TXFKF01QZMZ 1
68 TOP PANEL ASSY TXFKP01QYDZ 1 TXFKP01QZMZ 1
71 CARTON TPCC54403 1 TPCC54404 1
75 INSTRUCTION BOOK TQBJ0278 1 TQBJ0287 1
