Image preview - the first page of the document
>> Download Panasonic_TH-42PWD8GS_TH-37PWD8GS_TH-37PWD8EK_TH-37PWD8GK_TH-37PWD8ES_TH-42PWD8ES_TH-42PWD8GK_TH-37PWD8BS_TH-42PWD8UK_TH-42PWD8BK_TH-42PWD8BS_TH-37PWD8BK_TH-37PWD8UK_TH-42PWD8EK_[SM] documenatation <<Text preview - extract from the document ORDER NO. ITD0506035CE
D10 Canada: B07
Progressive Wide Plasma Display
TH-37PWD8BK
TH-37PWD8BS
TH-37PWD8EK
TH-37PWD8ES
TH-37PWD8GK
TH-37PWD8GS
TH-37PWD8UK
TH-42PWD8BK
TH-42PWD8BS
TH-42PWD8EK
TH-42PWD8ES
TH-42PWD8GK
TH-42PWD8GS
TH-42PWD8UK
GP8D Chassis
Specifications
Power Source (UK, GK/S) 120 V AC, 50/60 Hz (GK/GS/UK)
Power Source (EK/S, BK/S) 220-240 V AC, 50/60 Hz (EK/ES/BK/BS)
Power Consumption (UK, GK/S)
Maximum 225 W (37PWD8GK/GS/UK) 275 W (42PWD8GK/GS/UK)
Stand-by condition Save OFF 1.0 W, Save ON 0.7 W (GK/GS/UK)
Power off condition 0.05 W (GK/GS/UK)
Power Consumption (EK/S, BK/S)
Normal use 215 W (37PWD8EK/ES/BK/BS) 240 W (42PWD8EK/ES/BK/BS)
Stand-by condition Save off 1.2 W, Save on 0.9 W (EK/ES/BK/BS)
Power off condition 0.1 W (EK/ES/BK/BS)
