Image preview - the first page of the document



>> Download Panasonic_TH-42PX600_10_blinks_repair_tips documenatation <<

Text preview - extract from the document

 Panasonic Canada Inc.
 5770 Ambler Drive
 Mississauga ON
 L4W 2T3
                                                                    Tech Tips
 Product:                              Models:                            Number:
             PLASMA TV                                                              TT-08-22
                                                  TH42PX600
 Code:                                                                    Date:
             B62                                                                    May 29, 2008
                                       Model Year:     2006

PCB Designation: P Board

Part #:       TXN/P1BFTUS

Symptom:       Unit shuts down with power LED 10 blinks

Cause:         Shorted Q409 & open PR401

Remedy:        Replace Q409 & PR401




                     Q409:                                                   PR401:
          Part # B1DHCD000034                                        Part # K5Y502BA0001




                   Published by Customer & Product Assurance   TT-08-22                  Page 1
