Image preview - the first page of the document
>> Download Panasonic_TY-TP58P10S_[SM] documenatation <<Text preview - extract from the document ORDER NO. ITD0802007CE
Touch Panel
Model No. TY-TP58P10S
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2 6.1. Before the adjustment when Circuit board are
1.1. Prevention of Electrostatic Discharge (ESD) exchanged ------------------------------------------------- 42
to Electrostatically Sensitive (ES) Devices---------- 2 6.2. Cautions for replacing the Circuit board------------ 42
1.2. About lead free solder (PbF)---------------------------- 3 6.3. Flow chart for replacing the Boards ----------------- 42
2 Specifications ----------------------------------------------------- 4 6.4. How to rewrite data when replacing the Main
3 General/Introduction -------------------------------------------- 5 Board-------------------------------------------------------- 43
3.1. PCB Stracture ---------------------------------------------- 5 6.5. Adjust the optical axis----------------------------------- 43
4 Operating Instructions------------------------------------------ 6 6.6. Adjust PEAKPOSI (Corner) --------------------------- 45
5 Disassembly and Assembly Instructions ---------------40 6.7. Setting range (first, last) of the optical axis -------- 46
5.1. Remove the Frame U Assy ----------------------------40 6.8. Adjust and confirm the light level--------------------- 47
5.2. Remove the Cover-U Assy-----------------------------40 7 25-point calibration--------------------------------------------- 48
5.3. Remove the Flat bracing metal -----------------------40 7.1. Prepare setting for adjusting PC --------------------- 48
5.4. Remove the Main board unit---------------------------40 7.2. Explanation of 25-point Calibration ------------------ 48
5.5. Remove the Sensor-L board unit ---------------------40 8 Dimensions ------------------------------------------------------- 51
5.6. Remove the Sensor-R board unit --------------------40 9 Block Diagram --------------------------------------------------- 52
5.7. Remove the Right angle-UL ---------------------------41 10 Schematic Diagram -------------------------------------------- 53
5.8. Remove the Right angle-UR---------------------------41 10.1. Main Board Unit Schematic Diagram --------------- 53
6 Measurements and Adjustments---------------------------42 10.2. Sensor Board Unit Schematic Diagram ------------ 54
