Image preview - the first page of the document
![Panasonic_VieraLink_for_Technician_[TM]](/pics/5c27b9c6c477b.gif)
>> Download Panasonic_VieraLink_for_Technician_[TM] documenatation <<
Text preview - extract from the document
Technical Guide
Technical Guide
TM
VIErA Link Setup Series
Applies to :
Viera Link TM
& EZ Sync TM
& HDAVI Control TM
Panasonic Products
HDMI TM - CEC
(Consumer
Electronic
Control)
Panasonic Service and Technology Company
National Training
TTG090311HC/090513
Copyright Page
Prepared by
Instructor Herb Chin
Panasonic Service and Technology Company
National Training
Viera Link, HDAVI Control, and EZ Sync are registered trademarks of Matsushita Electric Industrial Co.
Dolby is a trademark of Dolby Laboratories All other trademarks are trademarks of their respective owners
"HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC."
Copyright 2009 by Panasonic Service and Technology Company
All rights reserved. Unauthorized copying and distribution is a violation of law.
Warning
This service information is designed for experienced repair technicians only and is not designed for use by the
general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in
attempting to service a product. Products powered by electricity should be serviced or repaired only by
experienced professional technicians. Any attempt to service or repair the product or products dealt with in this
service information by anyone else could result in serious injury or death.
Slide # 2
Contents
Page
Normal Viera Link Operation - What should Viera Link do? 4
Troubleshooting - Common symptoms & solutions 5
Setup - The Concept 8
TV Setup & testing 9
Home Theater Setup 11
DVD Product Setup 12
Final Testing 13
Sample Problems 15
Answers 22
Viera Cast Operation - What? How? & Where? 24
Alternate LAN hookup 29
Slide # 3
Normal Operation - What Can Viera Link do?
Viera Link Operation :
