Image preview - the first page of the document
>> Download A100 documenatation <<
Text preview - extract from the document
# No. DATA CONTENTS
MODIFICATION
#1 2000.2 Adds omitted parts numbers. (P.7-1, 7-2, 7-3, 7-4, 7-5, 7-6, 7-7, 7-8, 58)
HISTORY #2 2000.2 Alteration of parts supply, as the service division had changed. (P.6-1, 6-2)
#3 2000.2 Add the SONY badge. (P.6-1)
#4 2000.3 Decide on part number (IC901 on D board). (P.7-6)
MODEL NAME : HMD-A100 #5 2000.3 Parts number clerical error correction (C625 on D board). (P.7-4)
SERVICE MANUAL
#6 2000.5 Because a VAIO color model was added, nine parts were added to the Exploded Views.
PARTS No. : 9-978-660-01
(P.6-1, 6-2)
#7 2000.5 Add omitted part (LABEL, INFORMATION). (P.6-1)
* Blue characters are linking.
HMD-A100
SERVICE MANUAL US Model
Canadian Model
AEP Model
Chassis No. SCC-L27M-A
X11R CHASSIS
SPECIFICATIONS
CRT 0.24 mm aperture grille pitch * Recommended horizontal and vertical timing condition
15 inches measured diagonally ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
