Image preview - the first page of the document



>> Download G400 documenatation <<

Text preview - extract from the document

                                 # No.   DATA                                     CONTENTS
MODIFICATION
                                  #1     2000.5   Correct error in writing. (Addition of missing the D board for BRZ model and
  HISTORY                                         information labels.) (P.6-1)
                                  #2     2000.5   Correct error in writing. (Addition of missing factories.) (P.6-1, 6-3)
                                  #3     2000.5   Addition of EQ, NH, SH models. (P.6-1, 6-3)
MODEL NAME : CPD-G400
SERVICE MANUAL
PARTS No. : 9-978-652-01



* Blue characters are linking.
                                                                                  CPD-G400
SERVICE MANUAL                                                                     US Model
                                                                            Canadian Model
                                                                                AEP Model
                                                                             Brazilian Model
                                                                        N.Hemisphere Model
                                                                        S.Hemisphere Model
                                                                             Equator Model
                                                                                                Chassis No. SCC-L30A-A


                                                                                                F99 CHASSIS
                                                     SPECIFICATIONS
 CRT                   0.24 mm aperture grille pitch (center)   Deflection frequency*      Horizontal: 30 to 107 kHz
                       19 inches measured diagonally                                       Vertical: 48 to 120 Hz
                       90-degree deflection                     AC input voltage/current   120 V, 50/60 Hz, Max. 2.0 A
                       FD Trinitron                             Power consumption          140 W
 Viewable image size   Approx. 365
