                                                                           CPD-G500
SERVICE MANUAL                                                                     US Model
                                                                              Canadian Model
                                                                                  AEP Model
                                                                                         Chassis No. SCC-L22C-A
                                                                  S.Hemisphere Model
                                                                                         Chassis No. SCC-L22G-A
                                                                                    Equator Model
                                                                                         Chassis No. SCC-L22F-A




                                                                                            G1 CHASSIS
                                                 SPECIFICATIONS

 CRT                   0.24 mm aperture grille pitch     Deflection frequency*      Horizontal: 30 to 121 kHz
                       21 inches measured diagonally                                Vertical: 48 to 160 Hz
                       90-degree deflection              AC input voltage/current   100 to 240 V, 50
