Image preview - the first page of the document
GP8D TH-37PWD8BK TH-37PWD8BS TH-37PWD8EK TH-37PWD8ES TH-37PWD8GK TH-37PWD8GS TH-37PWD8UK TH-42PWD8BK TH-42PWD8BS TH-42PWD8EK TH-42PWD8ES TH-42PWD8GK TH-42PWD8GS TH-42PWD8UK


>> Download GP8D TH-37PWD8BK TH-37PWD8BS TH-37PWD8EK TH-37PWD8ES TH-37PWD8GK TH-37PWD8GS TH-37PWD8UK TH-42PWD8BK TH-42PWD8BS TH-42PWD8EK TH-42PWD8ES TH-42PWD8GK TH-42PWD8GS TH-42PWD8UK documenatation <<

Text preview - extract from the document
                                                                                                       ORDER NO. ITD0506035CE
                                                                                                              D10 Canada: B07




                                                                 Progressive Wide Plasma Display
                                                                  TH-37PWD8BK
                                                                  TH-37PWD8BS
                                                                  TH-37PWD8EK
                                                                  TH-37PWD8ES
                                                                  TH-37PWD8GK
                                                                  TH-37PWD8GS
                                                                  TH-37PWD8UK
                                                                  TH-42PWD8BK
                                                                  TH-42PWD8BS
                                                                  TH-42PWD8EK
                                                                  TH-42PWD8ES
                                                                  TH-42PWD8GK
                                                                  TH-42PWD8GS
                                                                  TH-42PWD8UK
                                                                  GP8D Chassis

Specifications
Power Source (UK, GK/S)          120 V AC, 50/60 Hz (GK/GS/UK)
Power Source (EK/S, BK/S)        220-240 V AC, 50/60 Hz (EK/ES/BK/BS)
Power Consumption (UK, GK/S)
   Maximum                       225 W (37PWD8GK/GS/UK)                        275 W (42PWD8GK/GS/UK)
   Stand-by condition            Save OFF 1.0 W, Save ON 0.7 W (GK/GS/UK)
   Power off condition           0.05 W (GK/GS/UK)
Power Consumption (EK/S, BK/S)
   Normal use                    215 W (37PWD8EK/ES/BK/BS)                     240 W (42PWD8EK/ES/BK/BS)
   Stand-by condition            Save off 1.2 W, Save on 0.9 W (EK/ES/BK/BS)
   Power off condition           0.1 W (EK/ES/BK/BS)
