Image preview - the first page of the document
GPF10D TH-50PF10UK


>> Download GPF10D TH-50PF10UK documenatation <<

Text preview - extract from the document
                                                                                                                    Order Number MTNC070939CE
                                                                                                                                   B34 Canada: D10




                                                                                High Definition Plasma Display
                                                                              Model No. TH-50PF10UK
                                                                              GPF10D Chassis




TABLE OF CONTENTS
                                                                    PAGE                                                                        PAGE
 1 Safety Precautions----------------------------------------------- 3             8.6.Removal of PB-Board----------------------------------- 21
     1.1. General Guidelines---------------------------------------- 3             8.7.Removal of DN-Board ---------------------------------- 21
 2 Warning -------------------------------------------------------------- 4        8.8.Removal of D-Board------------------------------------- 22
     2.1. Prevention of Electrostatic Discharge (ESD)                              8.9.Removal of P-Board------------------------------------- 22
          to Electrostatically Sensitive (ES) Devices---------- 4                 8.10.Removal of SU-Board and the SD-Board---------- 22
     2.2. About lead free solder (PbF)---------------------------- 5              8.11.Removal of SC-Board----------------------------------- 23
 3 Service Navigation ----------------------------------------------- 6           8.12.Removal of SS-Board ---------------------------------- 23
     3.1. Service Hint ------------------------------------------------- 6        8.13.Removal of H3-Board (L, R)--------------------------- 24
     3.2. Applicable signals ----------------------------------------- 7          8.14.Removal of Fan------------------------------------------- 24
 4 Specifications ----------------------------------------------------- 9         8.15.Removal of C1, C2, C3, C4, C5 and the C6-
 5 Operating Instructions-----------------------------------------10                   Board-------------------------------------------------------- 25
 6 Service Mode -----------------------------------------------------12          8.16. Removal of S1-Board ----------------------------------- 26
     6.1. CAT (Computer Aided Test) mode -------------------12                   8.17. Removal of Cabinet and Front Glass --------------- 27
     6.2. IIC mode structure (following items value is                           8.18. Removal of V1-Board and the V2-Board----------- 28
          sample data) -----------------------------------------------15         8.19. Removal of Plasma Panel ----------------------------- 28
 7 Troubleshooting Guide ----------------------------------------16            9 Measurements and Adjustments -------------------------- 32
     7.1. Self Check--------------------------------------------------16          9.1. Adjustment Procedure ---------------------------------- 32
     7.2. No Power ---------------------------------------------------18          9.2. Adjustment------------------------------------------------- 35
     7.3. No Picture --------------------------------------------------18     10 Block Diagram --------------------------------------------------- 41
     7.4. Local screen failure --------------------------------------19          10.1. Main Block Diagram ------------------------------------- 41
 8 Disassembly and Assembly Instructions ---------------20                       10.2. P-Board Block Diagram -------------------------------- 42
     8.1. Removal of Rear Cover ---------------------------------20              10.3. PB, V1 and V2-Board Block Diagram--------------- 43
     8.2. Removal of HA-Board -----------------------------------20              10.4. HA and HX-Board Block Diagram ------------------- 44
     8.3. Removal of HDMI-Board--------------------------------20                10.5. HDMI-Board (1 of 2) Block Diagram ---------------- 45
     8.4. Removal of DS-Board -----------------------------------20              10.6. HDMI-Board (2 of 2) Block Diagram ---------------- 46
     8.5. Removal of HX-Board -----------------------------------21
