Image preview - the first page of the document
>> Download GPF10D TH-65PF10UK documenatation <<
Text preview - extract from the document
ORDER NO. MTNC071042CE
B34 Canada:D10
High Definition Plasma Display
Model No. TH-65PF10UK
GPF10D Chassis
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 8.6.Removal of PB-Board----------------------------------- 21
1.1. General Guidelines---------------------------------------- 3 8.7.Removal of DN-Board ---------------------------------- 21
2 Warning -------------------------------------------------------------- 4 8.8.Removal of D-Board ------------------------------------ 21
2.1. Prevention of Electrostatic Discharge (ESD) 8.9.Removal of P-Board------------------------------------- 21
to Electrostatically Sensitive (ES) Devices---------- 4 8.10.Removal of SU-Board and SD-Board -------------- 22
2.2. About lead free solder (PbF)---------------------------- 5 8.11.Removal of SC-Board ---------------------------------- 22
3 Service Navigation ----------------------------------------------- 6 8.12.Removal of SS2-Board and SS3-Board ----------- 22
3.1. Service Hint ------------------------------------------------- 6 8.13.Removal of SS-Board ---------------------------------- 23
3.2. Applicable signals ----------------------------------------- 7 8.14.Removal of H3-Board (L), (R)------------------------- 23
4 Specifications ----------------------------------------------------- 9 8.15.Removal of C1, C2, C3, C4, C5 and C6-Board
5 Operating Instructions-----------------------------------------10 ---------------------------------------------------------------- 23
6 Service Mode -----------------------------------------------------12 8.16. Removal of S1-Board ----------------------------------- 25
6.1. CAT (computer Aided Test) mode --------------------12 8.17. Removal of Fan------------------------------------------- 25
6.2. IIC mode structure (following items value is 8.18. Removal of Cabinet ------------------------------------- 26
sample data) -----------------------------------------------15 8.19. Removal of V1-Board and V2-Board---------------- 26
7 Troubleshooting Guide ----------------------------------------16 8.20. Removal of Front Glass -------------------------------- 27
7.1. Self Check--------------------------------------------------16 8.21. Removal of Plasma Panel ----------------------------- 27
7.2. No Power ---------------------------------------------------18 9 Measurements and Adjustments -------------------------- 31
7.3. No Picture --------------------------------------------------18 9.1. Adjustment Procedure ---------------------------------- 31
7.4. Local screen failure --------------------------------------19 9.2. Adjustment------------------------------------------------- 34
8 Disassembly and Assembly Instructions ---------------20 10 Block Diagram --------------------------------------------------- 39
8.1. Removal of Rear Cover ---------------------------------20 10.1. Main Block Diagram ------------------------------------- 39
8.2. Removal of HA-Board -----------------------------------20 10.2. P-Board (1 of 2) Block Diagram ---------------------- 40
8.3. Removal of HDMI-Board--------------------------------20 10.3. P-Board (2 of 2) Block Diagram ---------------------- 41
8.4. Removal of DS-Board -----------------------------------20 10.4. PB, V1 and V2-Board Block Diagram--------------- 42
8.5. Removal of HX-Board -----------------------------------20 10.5. HA and HX-Board Block Diagram ------------------- 43
