Image preview - the first page of the document
>> Download VT20T Series Seminar documenatation <<
Text preview - extract from the document
E-Seminar
2010 VIErA (FHD 3D PDP)
VT20T series
Dongle (Wi-Fi)
3D Eyewear
1
Table of Contents
Lesson 1 Explanation about 3D
Lesson 2 Chassis structure and Signal circuit
Lesson 3 Picture Problem
Lesson 4 Power Supply Circuit
Lesson 5 Protection Circuit
Lesson 6 Troubleshooting of Power Supply Circuit
Lesson 7 Service Information
2
1. Explanation about 3D
3
1-1. 3D Format New
4/12
3D Signal Method
Item
Frame Sequential (FS) Side by Side (SBS) Top & Bottom (T&B) Checker Pattern Line by Line
HDMI Ver/1.4/ Under HDMI
Ver.1.3/ Digital signal from
Input HDMI Ver. 1.4 HDMI Ver.1.3 under/ HDMI Ver.1.4
PC etc.
broadcasting broadcasting
RL
L ...
L
Image L R
...
R
R
L
R
