Image preview - the first page of the document
>> Download th_42pf20e_er documenatation <<
Text preview - extract from the document
Order Number PCZ1004047CE
High Definition Plasma Display
Model No. TH-42PF20E
TH-42PF20ER
GPF13D Chassis
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions----------------------------------------------- 3 7.4. Local screen failure-------------------------------------- 20
1.1. General Guidelines---------------------------------------- 3 8 Service Fixture & Tools --------------------------------------- 21
1.2. Touch-Current Check ------------------------------------- 3 8.1. SC jig-------------------------------------------------------- 21
2 Warning -------------------------------------------------------------- 4 9 Disassembly and Assembly Instructions--------------- 22
2.1. Prevention of Electrostatic Discharge (ESD) 9.1. Removal of Rear Cover -------------------------------- 22
to Electrostatically Sensitive (ES) Devices---------- 4 9.2. Removal of Slot Block ---------------------------------- 22
2.2. About lead free solder (PbF)---------------------------- 5 9.3. Removal of DS-Board----------------------------------- 22
3 Service Navigation ----------------------------------------------- 6 9.4. Removal of HX-Board----------------------------------- 22
3.1. Service Hint ------------------------------------------------- 6 9.5. Removal of A-Board------------------------------------- 23
3.2. Applicable signals ----------------------------------------- 7 9.6. Removal of PB-Board----------------------------------- 23
4 Specifications ----------------------------------------------------- 9 9.7. Removal of Fan------------------------------------------- 23
5 Operating Instructions-----------------------------------------10 9.8. Removal of P-Board------------------------------------- 24
6 Service Mode -----------------------------------------------------12 9.9. Removal of AC Inlet Assy ----------------------------- 24
6.1. CAT (Computer Aided Test) mode -------------------12 9.10. Removal of H3-Board ----------------------------------- 24
6.2. IIC mode structure (following items value is 9.11. Removal of SM-Board ---------------------------------- 24
sample data) -----------------------------------------------16 9.12. Removal of SC-Board----------------------------------- 25
7 Troubleshooting Guide ----------------------------------------17 9.13. Removal of SS-Board----------------------------------- 25
7.1. Self Check--------------------------------------------------17 9.14. Removal of SS2-Board --------------------------------- 26
7.2. No Power ---------------------------------------------------19 9.15. Removal of S1-Board ----------------------------------- 26
7.3. No Picture --------------------------------------------------19 9.16. Removal of C1-Board ----------------------------------- 26
