Image preview - the first page of the document



>> Download p_p_c documenatation <<

Text preview - extract from the document

6

                                                                                                  P



     P-BOARD(COMPONENT SIDE)
     TNPA2490


5




4




                                                   Parts Location
                                                             P-BOARD (COMPONENT SIDE)
                                                    IC                    TRANSISTOR
                                                     IC801      B-3        Q804         E-5
3                                                    IC802      C-4        Q840         B-3
                                                     IC806      E-2        Q841         B-2
                                                     IC860      F-2        Q850         B-1
                                                     IC861      E-3        Q860         D-2
                                                     IC862      F-2        Q861         D-2
                                                     IC863      F-3        Q890         D-2
                                                                           Q891         B-1




2




1


    TU-PT600B                                                                      TU-PT600B
    P-BOARD TNPA2490                                                               P-BOARD TNPA2490
         A             B       C   D   E   F   G                      H                       I
