Text preview - extract from the document
6
P
P-BOARD(FOIL SIDE)
TNPA2490
5
4
Parts Location
P-BOARD (FOIL SIDE)
IC TP
IC801 E-3 TP824 B-2
3 IC802 E-4 TP841 B-2
IC806 C-2 TP842 A-3
IC861 B-3 TP843 A-2
IC863 A-3 TP844 B-2
IC864 B-3 TP856 D-2
IC865 C-1 TP860 A-2
TP861 B-2
TRANSISTOR TP862 B-2
Q804 C-5 TP863 B-2
Q805 E-2 TP864 C-2
Q840 F-3 TP865 C-2
Q841 F-2 TP866 D-2
Q862 B-2 TP867 D-2
Q863 B-3 TP869 F-2
2 Q864 B-3 TP870 E-2
Q1001 F-5 TP871 C-2
Q1002 F-4 TP872 F-4
TP873 E-1
TP874 D-2
TP8868 E-1
TPD5 E-4
TPD8 F-4
TPD12 F-5
1
TU-PT600B TU-PT600B
P-BOARD TNPA2490 P-BOARD TNPA2490
