Image preview - the first page of the document
>> Download MQM026DG290110REV1_6_TXP42S10_S11_U10_Paint_Effect documenatation <<
Text preview - extract from the document
Confidential
For Authorised Service Agents Only Ref No: MQM026DG290110REV1.6
TECHNICAL INFORMATION
A BY D EST H IS N PL SK UA Date 16.12.2009
AL CH DK F I L NL RO SLO FIN Country Reported
B CZ E GB IRL LT P S TR Europe
Product Category: Plasma TV / Plasma IDTV
Subject: Intermittent solarisation on lower half of picture
Model(s) Affected: TX-P42S10E/ES TX-P42S11B TX-P42U10E TX-PR42U10
TX-P42S10B TX-P42S11E TX-PF42S10
TX-P42S10L TX-P42U10B TX-PR42S10
Symptom / Intermittently the lower half of the picture displays a
Cause: solarisation effect.
Improvement of Q16743 circuit on SC board.
Remedy /
Method:
If the symptom appears, solder an additional resistor (Part number: ERJ6GEYF473) in parallel over R16747
See the diagrams below.
ERJ6GEYF473
Q16743
R16747
R16747
Warranty Claims - Please use the following IRIS and Activity codes
Activity Codes: Guarantee Status Repair Type Location Source
(UK Only) A R W D
Symptom Section Defect
Condition Repair
IRIS Codes: Area Type Code Area Code Area Code
2 3 2 328 3 DDC 5 P i
Note: Failure to use the correct IRIS and Activity codes may result in the claim being rejected
Document No: PUK-QST_TI
Panasonic 1 of 1 Rev: 9.00 DG310309
