Image preview - the first page of the document
>> Download TQB0E2212-1 documenatation <<
Text preview - extract from the document
Model No.
TX-P42GT50B
TX-P50GT50B
Operating Instructions
Plasma Television
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
The images shown in this manual are for illustrative purposes only.
English UK and Ireland model
TQB0E2212-1
Features
Smart VIERA DLNA
Digital smart life to create new and exciting TV DLNA is a standard that makes digital electronics
experiences (Networking / Easy Operation / Picture easier and more convenient to use on a home network.
Quality / Eco / Design) (p. 88)
3D technology VIERA Connect - Enjoy great web entertainment
You can enjoy viewing 3D images on this TV by (p. 20, 83)
wearing the 3D Eyewear. VIERA Connect allows you to access some specific
RealD 3D websites supported by Panasonic, and enjoy internet
This TV and 3D Eyewear use the 3D technology of contents such as videos, games, EPG, communication
RealD. RealD is one of the inventors in 3D technology. tools, etc. from VIERA Connect home screen.
freesat HD tuner built-in Link up and control the connected equipment with
This TV has a built-in freesat HD tuner. freesat is a free "Q-Link" and "VIERA Link" (p. 92)
digital TV service which broadcasts via satellite so you Q-Link and VIERA Link provide easy recording
can receive TV, radio, interactive TV, and HD TV with and playback, creation of a home theatre without
crystal clear reception. complicated settings, etc.
DVB-T2 tuner built-in VIERA TOOLS - Display special feature icons for
DVB-T2 is an advanced digital terrestrial system for easy accessibility (p. 39)
more efficient transmission. Special features (such as VIERA Link and Media
Available DVB-T2 broadcasts will be tuned Player) can be accessed easily by using the VIERA
automatically when you perform DVB Auto Setup. TOOLS button.
Wireless connection Dolby Digital Plus / Dolby Pulse decoders
This TV can be connected to the network with the built- It is possible to decode Dolby Digital Plus / Dolby Pulse
in wireless LAN. Also can be connected to the specific multi-channel audio tracks and output as Dolby Digital
devices supporting Bluetooth wireless technology (3D Bitstream (multi-channel sound signal) from DIGITAL
Eyewear, Keyboard, Audio devices) AUDIO OUT / HDMI2 (ARC function) terminals.
Using USB devices Owner ID (p. 64)
Enjoy recording and playback the digital TV Owner ID is an anti-theft function. Entering the PIN
programmes to the USB HDD. (p. 69, 78) number and owner's personal information will help the
Enjoy the photo, video and music in the USB Flash Police to determine the owner in the case of theft.
Memory on Media Player. (p. 72) Voice Guidance (p. 23, 44)
USB keyboard, gamepad, etc. are available. (p. 108) Voice Guidance narrates the operation of the basic
Timer Programming (p. 27, 60) features (EPG, on-screen messages, etc.) to assist
Timer Programming enables you to use functions such visually-impaired users.
as programme reminder and programme recording to Supports Audio Description signal (p. 23, 44)
the external recorder or formatted USB HDD. Audio Description (when broadcast) adds an additional
SDXC Card soundtrack to describe events on screen (narration)
This TV supports SDXC Card. SDXC is the latest and aids understanding and enjoyment, particularly for
standard of SD Card and a higher storage capacity card. visually-impaired users.
Digital Switchover for Terrestrial broadcasts
Starting in late 2007 and ending in 2012, TV services in the UK will go completely digital, TV region by TV region.
If you have any questions, please call Digital UK on 08456 50 50 50 or visit www.digitaluk.co.uk
Digital Switchover will cover a period of several weeks. When it starts you will lose all Analogue TV channels and
some Digital TV channels will be missing.
You will need to retune your TV each time this happens to recover your digital channels. Analogue channels are
permanently turned off, it will not be possible to recover them.
To retune your TV [Auto Setup] in [DVB Tuning Menu]-DVB mode (p. 53)
Users of cable or satellite boxes should still retune the TV to continue to receive Freeview channels via their aerial.
(Your Analogue channel for viewing Cable or Satellite services will change to a new position.)
Due to the digital reception technologies involved, quality of the digital signals may be relatively low in some cases,
despite good reception of analogue channels.
Notice for DVB / Data broadcasting / IPTV functions
This TV is designed to meet the standards (as of August, 2011) of digital services.
Not all the features are available depending on the country, area, broadcaster, service provider and network
environment.
The compatibility with future services is not guaranteed.
Check the latest information on the available services at the following website.
http://panasonic.jp/support/global/cs/tv/
2
Do not display any still part of the image for
a long period
Contents
In such cases the still part of the image remains dimly on the
plasma screen ("image retention"). This is not considered a Be Sure to Read
malfunction and is not covered by the warranty.
