Image preview - the first page of the document
>> Download PCZ1203032BE documenatation <<Text preview - extract from the document ORDER No. PCZ1203032BE
Service Hint
Plasma Display Television
Models: TX-P50GT30B, TX-P50GT30J, TX-P50GT30E, TX-P50GT30Y, TX-PR50GT30
TX-P50ST30B, TX-P50ST30J, TX-P50ST30E, TX-PF50ST30, TX-PR50ST30,
TX-P50ST31B, TX-P50ST33J, TX-P50ST33E, TX-P50ST32Y
Subject: Compatibility of Spare Parts PDP panels
Supplied PDP panel Order No. MD50F14C9Z, MD50F14C4Z
Information: If the underside chassis (placed on C-Board) is different to defective panel's one,
please remove it from defective panel, then use it to new panel.
Bottom side of panel.
CONTACT METAL BOTTOM
Part No. TUX3DJ080, TUX3DJ090
