Image preview - the first page of the document



>> Download 53wx_01 documenatation <<

Text preview - extract from the document

                                                                                                           ORDER NO. MTNC020517A1
                                                                                                           B2




Service Manual                                                                      HDTV MONITOR
            ed
       plifi                                                                      Simplified Manual
                                                                                       (P7W)

    Sim
                                                                                         Panasonic
                                                                           Models                               Chassis
                                                                      PT-53WX52F                                       EP824
                                                                      PT-53WX52CF                                      EP824
                                                                      PT-53WX42F                                       EP824
                                                                      PT-56WX52F                                       FP824
                                                                      PT-56WX52CF                                      FP824
                                                                      PT-56WX42F                                       FP824




                            PT-56WX52F


This Simplified Service Manual is issued to add listed models to the Simplified Service Manual order
No.MTNC020411C1 (PT-47WX52F). Included in this manual are disassembly procedures, and a complete parts list for
the serviceable boards are included in this Simplified Manual. Please file and use this manual together with Simplified
Service Manual, order No. MTNC020411C1 (PT-47WX52F).

"WARNING! This Service Manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death."

The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in the Main Manual.


                                                                                 Copyright 2002 by Matsushita Electric Corporation of
                                                                                 America. All rights reserved. Unauthorized copying
                                                                                 and distribution is a violation of law.
