Image preview - the first page of the document



>> Download tx-29pn1_110 documenatation <<

Text preview - extract from the document

                                                                                                          ORDER No. PCZ0504048C2




 Service Manual
                                                                                     Colour Television
                                                                              TX-29PN1D, TX-29PN1F,
                                                                                         TX-29PN1P,
                                                                              TX-28PN1D, TX-28PN1F,
                                                                                         TX-28PN1P,

                                                                                               GP4L Chassis

SPECIFICATIONS
(Information in brackets [ ] refers to models 28")
                                                                     AV2 IN                  Video (21 pin)      1V p-p 75
                                                                                             Audio (21 pin)      500mV rms 10k
Power Source:                220-240V a.c., 50Hz                                             S-Video IN          Y: 1V p-p 75
                                                                                             (21-pin)            C:0,3V p-p 75
Power Consumption:           68W [65W]
                                                                     AV2 OUT                 Video (21 pin)      1V p-p 75
Stand-by Power                                                                               Audio (21 pin)      500mV rms 1k
Consumption:                 1W
                                                                     AV3 IN                  Audio (RCAx2)       500mV rms 10k
Aerial Impedance:            75 unbalanced, Coaxial Type                                     Video (RCAx1)       1V p-p 75

Receiving System:            PAL-I, B/G, D/K, PAL-525/60
                             SECAM B/G, D/K, L/L'                    High Voltage:           31kV
