Image preview - the first page of the document
>> Download tx28sl20c documenatation <<Text preview - extract from the document ORDER No. SM-99080
6HUYLFH 0DQXDO
Colour Television
TX-28SL20C
EURO-4H Chassis
SPECIFICATIONS TECHNISCHE DATEN
Power Source: 220-240V a.c., 50Hz Netzpannung: 220-240V a.c., 50Hz
Power Consumption: 121W Leistungsaufnahme: 121W
Standby Power Standby
Consumption: 1,4W Leistungsaufnahme: 1,4W
Aerial Impedance: 75 unbalanced, Coaxial Type Antennenimpedanz: 75 asymmetrisch, Koaxial-Typ
Receiving System: PAL-B/G, H, D/K, PAL-525/60 Empfangssystem: PAL-B/G, H, D/K, PAL-525/60
SECAM B/G, D/K SECAM B/G, D/K
M.NTSC M.NTSC
NTSC (AV only) NTSC (nur AV Eingang)
Receiving Channels: Empfangsbereiche:
VHF E2-E12 VHF H1-H2 (ITALY) VHF E2-E12 VHF H1-H2 (ITALY)
VHF A-H (ITALY) VHF R1-R2 VHF A-H (ITALY) VHF R1-R2
VHF R3-R5 VHF R6-R12 VHF R3-R5 VHF R6-R12
UHF E21-E69 CATV (S01-S05) UHF E21-E69 CATV (S01-S05)
CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10) CATV S1-S10 (M1-M10) CATV S11-S20 (U1-U10)
CATV S21-S41 (HYPERBAND) CATV S21-S41 (HYPERBAND)
Intermediate Frequency: Zwischenfrequenz:
Video 38,9MHz Video 38,9MHz
Sound 33,16MHz, 33,4MHz Sound 33,16MHz, 33,4MHz
32,4MHz (A2 STEREO) 32,4MHz (A2 STEREO)
33,05MHz, 34,05MHz (NICAM) 33,05MHz, 34,05MHz (NICAM)
Colour 34,47MHz (PAL) Colour 34,47MHz (PAL)
34,5MHz, 34,65MHz (SECAM) 34,5MHz, 34,65MHz (SECAM)
Video/Audio Terminals: Video/Audio Anschl
