Image preview - the first page of the document



>> Download tx32pl10 documenatation <<

Text preview - extract from the document

                                                                                                      ORDER No. SM-01030




                                                                             Colour Television
                                                                                   TX-32PL10D
                                                                                   TX-32PL10F
                                                                                   TX-32PL10P
                                                                           EURO-4H Chassis
SPECIFICATIONS
Power Source:             220-240V a.c., 50Hz                AV2 IN                  Video (21 pin)      1V p-p 75
                                                                                     Audio (21 pin)      500mV rms 10k
Power Consumption:        140W                                                       S-Video IN          Y: 1V p-p 75
                                                                                     (21-pin)            C:0,3V p-p 75
Stand-by Power
Consumption:              1.4W                               AV2 OUT                 Video (21 pin)      1V p-p 75
                                                                                     Audio (21 pin)      500mV rms 1k
Aerial Impedance:         75 unbalanced, Coaxial Type                                Selectable output (21 pin)
                                                             AV3 IN                  S-Video IN          Y: 1V p-p 75
Receiving System:         PAL-I, B/G, H, D/K, PAL-525/60
                                                                                     (4-pin)             C: 0,3V p-p 75
                          SECAM L/L', B/G, D/K
                                                                                     Audio (RCAx2)       500mV rms 10k
                          M.NTSC
                          NTSC (AV only)                                             Video (RCAx1)       1V p-p 75

                                                             High Voltage:           32kV
