Image preview - the first page of the document



>> Download panasonic_ap395_chassis_ct2022hbf_tv_sm documenatation <<

Text preview - extract from the document

                                                                                                      ORDER NO. MTNC020827A1
                                                                                                      B1




Service Manual                                                                 Color Television

              ied                                                           Simplified Manual
          plif                                                                  (NA7D)

       Sim                                                                          Panasonic
                                                                    Models                                   Chassis
                                                                    CT-2022HBF                                AP395
                                                                    CT-2022HBCF                               AP395




 This simplified service manual is issued to add the models of the NA7D family listed above to main manual order No.
 MTNC010734C1 (CT-2022HE). Included in this simplified service manual are unique characteristics and a complete
 parts list. Please file and use together with the main service manual order No. MTNC010734C1 (CT-2022HE) and
 related manuals.


"WARNING! This service manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service manual by anyone else could result in serious injury or death."


The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in this Manual.


                                                                                    Copyright 2002 by Matsushita Electric Corporation of
                                                                                    America. All rights reserved. Unauthorized copying
                                                                                    and distribution is a violation of law.
                                   Important safety notice
Special components are used in this television set which are important for safety. These parts are identified on the
schematic diagram by the symbol         and printed in BOLD TYPE on the replacement part list. It is essential that
these critical parts are replaced with the manufacturer's specified replacement part to prevent X-ray radiation,
shock, fire or other hazards. Do not modify the original design without the manufacturer's permission.
                                            Safety precautions
General guidelines                                            antenna terminals, control shafts, etc. If the exposed
An isolation transformer should always be used                metallic part has a return path to the chassis, the
during the servicing of a Receiver whose chassis is not       reading should be between 240k and 5.2M. If the
isolated from AC power line. Use a transformer of             exposed metallic part does not have a return path to
adequate power rating as this protects the technician         the chassis, the reading should be infinite.
from accidents resulting in personal injury from              Leakage current hot check (Fig. 1)
electrical shocks. It will also protect the Receiver from     Plug the AC cord directly into the AC outlet. Do not use
being damaged by accidental shorting that may occur           an isolation transformer during the check.
during servicing.                                             Connect a 1.5k 10 watt resistor in parallel with a
When servicing, observe the original lead dress,              0.15
