Image preview - the first page of the document



>> Download CT-32HX40B documenatation <<

Text preview - extract from the document

                                                                                                          ORDER NO. MTNC000626C1
                                                                                                          B5




Service Manual                                                                    Color Television



                                                                                    Main Manual
                                                                                      (DX2P)


                                                                                      Panasonic
                                                                     Models                                     Chassis
                                                                 CT-32HX40B                                        AP346
                                                                 CT-32HX40CB                                       AP346
                                                                 CT-36HX40B                                        AP347
                                                                 CT-36HX40CB                                       AP347




 This Service manual is issued as a service guide for the models of the DX2P family listed above. Included in this
 manual are a set of schematics, block diagrams, functional descriptions, alignment procedures, disassembly
 procedures, and a complete parts list.


"WARNING! This Service Manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death."


The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in this Main Manual.

                                                                                 Copyright 2000 by Matsushita Electric Corporation of
                                                                                 America. All rights reserved. Unauthorized copying
                                                                                 and distribution is a violation of law.
