Image preview - the first page of the document
>> Download PANASONIC service mode documenatation <<
Text preview - extract from the document
ORDER No. 03-SM-001
Colour Television
TX-32PS1
TX-28PS1
EURO- 10 Chassis
SPECIFICATIONS
(Information in brackets [ ] refers to model TX-28PS1)
AV2 IN Video (21 pin) 1V p-p 75W
Power Source: 220-240V a.c., 50Hz Audio (21 pin) 500mV rms 10kW
S-Video IN Y: 1V p-p 75W
Power Consumption: 90W [85W] (21-pin) C:0,3V p-p 75W
Stand-by Power AV2 OUT Video (21 pin) 1V p-p 75W
Consumption: 1,0W Audio (21 pin) 500mV rms 1kW
Aerial Impedance: 75W unbalanced, Coaxial Type AV3 IN S-Video IN Y: 1V p-p 75W
(4-pin) C:0,3V p-p 75W
Receiving System: PAL I, PAL-525/60
Audio (RCAx2) 500mV rms 10kW
M.NTSC (AV only)
NTSC (AV only) Video (RCAx1) 1V p-p 75W
Receiving Channels: UHF E21-E68 High Voltage: 32,0kV ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
