Image preview - the first page of the document
Panasonic_TX32DK1F_ch_EURO4 - SM[1].part1


>> Download Panasonic_TX32DK1F_ch_EURO4 - SM[1].part1 documenatation <<

Text preview - extract from the document
                                                                                                          ORDER No. SM-99084




6HUYLFH 0DQXDO
                                                                                   Colour Television
                                                                                                     TX-32DK1F
                                                                                     EURO-4 Chassis
SPECIFICATIONS                                                      TECHNISCHE DATEN
Power Source:               220-240V a.c., 50Hz                     Netzpannung:               220-240V a.c., 50Hz
Power Consumption:          95W                                     Leistungsaufnahme:         95W
Standby Power                                                       Standby
Consumption:                1,4W                                    Leistungsaufnahme:         1,4W
Aerial Impedance:           75 unbalanced, Coaxial Type             Antennenimpedanz:          75 asymmetrisch, Koaxial-Typ
Receiving System:           PAL-B/G, H, I, D/K, PAL-525/60          Empfangssystem:            PAL-B/G, H, I, D/K, PAL-525/60
                            SECAM B/G, D/K, L/L'                                               SECAM B/G, D/K, L/L'
                            M.NTSC                                                             M.NTSC
                            NTSC (AV only)                                                     NTSC (nur AV Eingang)
Receiving Channels:                                                 Empfangsbereiche:
VHF E2-E12                       VHF H1-H2 (ITALY)                  VHF E2-E12                    VHF H1-H2 (ITALY)
VHF A-H (ITALY)                  VHF R1-R2                          VHF A-H (ITALY)               VHF R1-R2
VHF R3-R5                        VHF R6-R12                         VHF R3-R5                     VHF R6-R12
UHF E21-E69                      CATV (S01-S05)                     UHF E21-E69                   CATV (S01-S05)
CATV S1-S10 (M1-M10)             CATV S11-S20 (U1-U10)              CATV S1-S10 (M1-M10)          CATV S11-S20 (U1-U10)
CATV S21-S41 (HYPERBAND)                                            CATV S21-S41 (HYPERBAND)
Intermediate Frequency:                                             Zwischenfrequenz:
Video                            38,9MHz, 34MHz                     Video                         38,9MHz, 34MHz
Sound                            32,9MHz, 33,16MHz, 33,4MHz         Sound                         32,9MHz, 33,16MHz, 33,4MHz
                                 40,4MHz, 32,4MHz (A2 STEREO)                                     40,4MHz, 32,4MHz (A2 STEREO)
                                 33,05MHz, 34,05MHz (NICAM)                                       33,05MHz, 34,05MHz (NICAM)
                                 32,66MHz, 32,4MHz (CZECH STEREO)                                 32,66MHz, 32,4MHz (CZECH STEREO)
Colour                           34,47MHz (PAL)                     Colour                        34,47MHz (PAL)
                                 34,5MHz, 34,65MHz (SECAM)                                        34,5MHz, 34,65MHz (SECAM)
Video/Audio Terminals:                                              Video/Audio Anschl
