Image preview - the first page of the document
>> Download Panasonic_TC-14A04P_TC-20A04P_TC-20B04 Chassis GP3 documenatation <<
Text preview - extract from the document
Service Manual
Order DCS - JUN2004 - 004 - MS
GP3 CHASSIS Color Television
TC-14A04P
TC-20A04P
TC-20B04
Specifications
MODEL
ITEM TC-14A04P TC-20A04P TC-20B04
Power source 110/220 V AC 110/220 V AC 110/220 V AC
50/60 Hz automatic switch 50/60 Hz automatic switch 50/60 Hz automatic switch
Consumption 51 W 61 W 61 W
Antenna input jack 75 ohms - VHF/UHF/CATV 75 ohms - VHF/UHF/CATV 75 ohms - VHF/UHF/CATV
Color systems PAL-M/NTSC/PAL-N PAL-M/NTSC/PAL-N PAL-M/NTSC/PAL-N
Tuning system F.S.T. F.S.T. F.S.T.
Channel capability 2 to 13 (VHF) 2 to 13 (VHF) 2 to 13 (VHF)
14 to 69 (UHF) 14 to 69 (UHF) 14 to 69 (UHF)
1 to125 (CATV) 1 to125 (CATV) 1 to125 (CATV)
Picture tube (Diagonal Visual) Panablack 33 cm Panablack 48cm Panablack 48cm
Audio output 3 W RMS 3 W RMS 3 W RMS
Video input jack 1 AV (rear) 1AV (rear) 1 (front) 1(rear)
Video Outlet 1 (back) 1 (back) 1 (back)
Dimension (width, height, depth) 370 x 351 x 366 mm 502 x 455 x 471 mm 502 x 455 x 471 mm
Weight 9,6 kg 17 kg 17 kg
Specifications are subject to change without notice. Weight and dimensions shown are approximate.
Supplied Accessories:
