Image preview - the first page of the document
>> Download panasonic_tc-14z88rq_ch_gp3_sm documenatation <<Text preview - extract from the document 308269c3.html
Table Of Contents
Service Manual
COVER
1 Safety Precautions TOP NEXT
1.1 General Guide Lines
1.2 Leakage Current Cold ORDER NO. MTV0308269C3
Check
1.3 Leakage Current Hot
Check (Fig. 1)
1.4 X-Radiation
1.5 GP3 Chassis Block
Diagram
2 Service Hints
2.1 Service Position for E-
Board Colour Television
2.2 Factory Mode Adjustment
2.3 Adjustment for White q TC-14Z88RQ
Balance
2.4 Adjustment for CRT CUT GP3 Chassis
OFF
2.5 Adjustment Procedure
2.6 PAL Colour
2.7 Adjustment
3 Conductor Views
4 Schematic Diagram
4.1 A BOARD
4.1.1 A BOARD (1 / 5)
4.1.2 A BOARD (2 / 5)
4.1.3 A BOARD (3 / 5)
4.1.4 A BOARD (4 / 5)
4.1.5 A BOARD (5 / 5)
4.2 L BOARD
4.2.1 L BOARD (1 / 2)
4.2.2 L BOARD (2 / 2)
5 Part Location
6 Replacement Parts List
6.1 Replacement Parts List
Specifications
file:///C|/Documents and Settings/eDOK/ 01>G89 AB>;/GP3 Ch_TC-14Z88RQ.htm (1 of 3)10.02.2006 2:27:21
308269c3.html
Power Source : AC AUTO 110-240V, 50/60 Hz
Power 61W
Consumption :
Aerial Impedance : 75 unbalanced
Coaxial type
Receiving System : 17 Systems
Receiving
Channels :
VHF 1-11 PAL B (Australia& N.Zealand)
1-12 PAL/SECAM D
1-12 NTSC M JAPAN
2-12 PAL/SECAM B, G
2-13 NTSC M U.S.A.
UHF 21-69 PAL G I/SECAM B, G, K1
28-69 PAL G (Australia)
13-56 PAL D
13-52 NTSC M JAPAN
14-69 NTSC NTSC M U.S.A.
CATV S1-S41 (Hyper)
Intermediate Frequency :
Video 38.0 MHz
Sound 31.5 MHz (D, K, K1)
32 MHz (I)
32.5 MHz (B, G)
33.5 MHz (M)
Colour 33.57 MHz (PAL)
33.6 MHz (SECAM)
33.75 MHz (SECAM)
34.42 MHz (NTSC)
Video/ Audio Terminals :
RAV In Video In 1 Vp-p 75
Audio In Approx. 400mVrms
Monitor Out Video Out 1 Vp-p 75
Audio Out Approx. 400mVrms
High Voltage : 24.5kV
