Image preview - the first page of the document



>> Download TX-21JT1_EU_SVC documenatation <<

Text preview - extract from the document

                                                                                                ORDER No. 00-SM-003




                                                                                  Colour Television
                                                                                               TX-21JT1
                                                                                               TX-14JT1
                                                                                               TC-14JR1
                                                                                                Z7 Chassis



 SPECIFICATION
(Information in brackets {} refer to TX-14JT1,TC-14JR1)


Power Source:                 220-240V a.c., 50Hz            RCA IN              Video 1V p-p 75
                                                             RCA IN              Audio 500mV rms 10k
Power Consumption:            53W {33W}
                                                            High Voltage:         26,7kV
