Image preview - the first page of the document
>> Download TX32PF10+TX36-Euro5- documenatation <<
Text preview - extract from the document
ORDER No. SM-98074
Colour Television
TX-36PF10
TX-32PF10
EURO-5 Chassis
SPECIFICATIONS
(Information in brackets { } refer to TX-32PF10)
Power Source: 220-240V AC, 50Hz AV3 IN S-Video IN Y: 1V p-p 75
(4-pin) C: 0,3V p-p 75
Power Consumption: 162W {155W} Audio(RCAx2) 500mV rms10k
Video (RCAx1) 1V p-p 75
Aerial Impedance: 75 unbalanced, Coaxial Type AV4 IN Video (21 pin) 1V p-p 75
Audio (21 pin) 500mV rms 10k
Stand-by Power S-Video IN Y: 1V p-p 75
Consumption: 1,9W (21 pin) C: 0.3V p-p 75
AV4 OUT Video (21 pin) 1V p-p 75
Receiving System: PAL I, PAL 525/60
Audio (21 pin) 500mV rms 1k
M.NTSC
NTSC (AV only)
