Service Manuals, User Guides, Schematic Diagrams or docs for : panasonic TV TXW28R4-Euro4

<< Back | Home

Most service manuals and schematics are PDF files, so You will need Adobre Acrobat Reader to view : Acrobat Download Some of the files are DjVu format. Readers and resources available here : DjVu Resources
For the compressed files, most common are zip and rar. Please, extract files with Your favorite compression software ( WinZip, WinRAR ... ) before viewing. If a document has multiple parts, You should download all, before extracting.
Good luck. Repair on Your own risk. Make sure You know what You are doing.



Image preview - the first page of the document



>> Download TXW28R4-Euro4 documenatation <<

Text preview - extract from the document

                                                                                                    ORDER No. SM-98058




                                                                            Colour Television
                                                                                             TX-W28R4


                                                                                EURO4 Chassis
SPECIFICATIONS
                                                            AV3 IN                  S-Video IN          Y: 1V p-p 75
Power Source:             220-240V AC, 50Hz                                         (4-pin)             C: 0,3V p-p 75
                                                                                    Audio (RCAx2)       500mV rms10k
Power Consumption:        100W                                                      Video (RCAx1)       1V p-p 75

Aerial Impedance:         75 unbalanced, Coaxial Type
                                                            High Voltage:           30,5kV
