Image preview - the first page of the document



>> Download panasonic_ct-32sx31e_na8ml documenatation <<

Text preview - extract from the document

                                                                                                       ORDER NO. MTNC010524C1
                                                                                                       B5




Service Manual                                                                   Color Television


                                                                                    Main Manual
                                                                                         (NA8ML)


                                                                                       Panasonic

                                                                       Models                                  Chassis
                                                                     CT-32SX31E                                   BP371
                                                                     CT-32SX31UE                                  BP371
                                                                     CT-32SX31CE                                  BP371
                                                                     CT-36SX31E                                   BP372
                                                                     CT-36SX31UE                                  BP372
                                                                     CT-36SX31CE                                  BP372




 This Service manual is issued as a service guide for the models of the NA8ML family listed above. Included in this
 manual are a set of schematic, block diagrams, functional descriptions, alignment procedures, disassembly
 procedures and a complete parts list.


"WARNING! This Service Manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death."



The service technician is required to read and follow the "Safety Precautions" and "Important Safety Notice" in this Main Manual.

                                                                                Copyright 2001 by Matsushita Electric Corporation of
                                                                                America. All rights reserved. Unauthorized copying
                                                                                and distribution is a violation of law.
