                      NICAM DECODER PACK C.B.A.
                      Integrated Circuit
                         IC7301          B-2
                         IC7302          A-2
                      Test Point
                         TL7301          A-2
                         TL7303          B-2
                         TL7304          B-2
                      Integrated Circuit
                         PK7301          A-1
                         PK7302          A-2
                      ADDRESS INFORMATION




    (VEP07A18J)



C




B




A




         1        2                  3
