Image preview - the first page of the document
>> Download c_main documenatation <<
Text preview - extract from the document
IMPORTANT SAFETY NOTICE:
REF. NO. 4000 COMPONENTS IDENTIFIED WITH THE MARK HAVE
SERIES REF. NO. 4500 SERIES THE SPECIAL CHARACTERISTICS FOR SAFETY.
WHEN REPLACING ANY OF THESE COMPONENTS.
REF. NO. 3000 SERIES
USE ONLY THE SAME TYPE.
Parts No. Model No. Mark
F (D.E.F)
VEP06D77A NV-HS960EG-S (D)
VEP06D77B NV-HS960B-S (E)
VEP06D77C NV-HS960EC-S (F)
VEP06D77E NV-HS860EG-K (A)
NV-HS860EG-S
VEP06D77F NV-HS860B-S (B)
VEP06D77G NV-HS860EC-S (C)
MAIN C.B.A.
Transistor QR6003 B-3
Q1001 A-1 QR6701 F-2
(B.E) Q1002 A-1 QR6702 F-2
(D.E.F) Q1003 A-1 QR7501 B-1
Q1006 B-1 QR7601 E-8
E REF. NO. 2500 SERIES (B.E)
Q1007 A-1 Integrated Circuit
Q1010 B-1 IC1001 B-1
Q1051 B-8 IC1051 B-8
Q1052 A-8 IC1080 B-8
Q1055 A-7 IC1081 C-8
REF. NO. 7600 SERIES
Q1056 A-7 IC2501 D-1
Q1057 A-8 IC2502 F-1
Q1058 A-8 IC3001 E-4
Q1080 B-8 IC3201 A-6
Q1081 B-8 IC3301 C-5
Q1082 C-8 IC3302 B-6
Q1504 C-1 IC3303 B-6
Q1505 C-6 IC4501 E-7
D Q3001 D-5 IC4502 A-8
Q3201 F-4 IC4503 F-6
DU7601 Q3301 C-6 IC6001 C-3
Q3302 C-6 IC6002 B-5
Q3303 C-6 IC6003 B-3
Q3304 C-6 IC6004 D-3
Q3305 C-4 IC6701 F-2
Q4001 E-2 IC7501 A-4
Q4002 D-3 IC7503 A-3
Q4003 E-4 IC7504 A-5
Q4004 E-4 Test Point
Q4101 C-7 TL2001 B-2
Q4102 D-6 TL2502 B-4
T-PHOTO
Q7601 B-8 TL2503 C-2
C Q7651 A-8 TL3001 D-4
S-PHOTO Q7652 A-8 TL3301 D-5
Q7653 A-8 TL3302 D-5
Transistor & Resistor TL4509 E-7
QR1001 A-1 TL6010 B-2
QR1005 B-1 TL6013 B-5
QR1051 A-7 TW2015 D-1
(B.C.E.F) QR1052 A-8 TW3001 D-7
QR1080 B-8 TW3002 D-6
QR1081 B-8 Adjustment
REF. NO. 1000 SERIES
QR2504 D-3 VR3002 D-6
QR2505 C-3 VR3004 D-6
REF. NO. 3000 QR3001 D-6 VR3005 D-7
SERIES QR3002 D-6 Connector
B
QR3003 E-5 P1001 B-1
QR3201 F-4 P1501 E-2
QR3301 C-4 P2501 C-2
QR3302 C-4 P2502 F-1
QR3303 C-4 P3001 F-5
REF. NO. 1000 SERIES
REF. NO. 6000 SERIES QR3307 C-5 P3002 F-4
QR3309 C-4 P4001 F-3
QR3310 C-6 P4101 D-6
QR4001 D-3 P7501 A-2
S-VHS QR4002 D-3 P7502 A-6
DET
QR4003 E-2 PK7301 B-8
QR4007 F-3 PK7302 B-8
QR4008 E-3 PP3501 C-7
SAFETY
TAB
QR4009 E-3 PP3502 D-7
A QR4101 C-7 PP3503 D-7
QR4501 F-6 PP3901 F-7
QR4502 F-5 PP3902 F-6
QR4503 F-6 PP3903 F-5
QR4504 F-6 PP3904 F-4
QR4506 F-6 PP3905 F-4
REF. NO. 7500 SERIES
QR4507 F-6 PP7701 F-3
QR6001 B-3 PP7702 F-2
QR6002 C-1 PP7703 F-1
