Image preview - the first page of the document



>> Download ds06w01 documenatation <<

Text preview - extract from the document

T1150-2 STOP             T1150-4 STOP             T1150-6 STOP             T1150-11 STOP            T1150-12 STOP
3.8Vp-p (2msec.div.)     560Vp-p (5usec.div.)     33Vp-p (5usec.div.)      100Vp-p (5usec.div.)     18Vp-p (5usec.div.)




T1150-13 STOP            T1150-16 STOP            Q1200-1 STOP             IC2501-22,23,25 PLAY     IC6001-13 STILL
40Vp-p (5usec.div.)      76Vp-p (5usec.div.)      0.4Vp-p (5usec.div.)     7.0Vp-p (2msec.div.)     5.0Vp-p (5msec.div.)




IC6001-18 REC            IC6001-50 REC/PLAY       IC6001-52 REC/PLAY       IC6001-68,69 REC         IC6001-70 REC
5.0Vp-p (10msec.div.)    2.0Vp-p (20usec.div.)    2.0Vp-p (20usec.div.)    5.0Vp-p (5msec.div.)     5.0Vp-p (5msec.div.)




IC6001-71 REC            IC6001-72 REC            IC6001-79,80 FF/REW      IC6001-90 REC            IC6001-94,95 REC
5.0Vp-p (5usec.div.)     5.0Vp-p (5msec.div.)     5.0Vp-p (1msec.div.)     5.0Vp-p (10msec.div.)    6.8Vp-p (10msec.div.)




IC6001-97 PLAY           IC3001-6 REC/PLAY        IC3001-17 REC            IC3001-26 REC            IC3001-29 REC/PLAY
0.8Vp-p (10msec.div.)    1.2Vp-p (0.5msec.div.)   1.2Vp-p (20
