Image preview - the first page of the document
>> Download sh_audio documenatation <<
Text preview - extract from the document
VIDEO MAIN SIGNAL PATH IN REC MODE AUDIO MAIN SIGNAL PATH IN REC MODE NAVIGATION
VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE AUDIO MAIN SIGNAL PATH IN PLAYBACK MODE INTERCONNECTION
MAIN PCB - TIMER
MAIN PCB - SYSCON-SERVO
MAIN PCB - VIDEO I/O 1/2
G MAIN PCB - VIDEO I/O 2/2
NV-HV61EG-S NV-HV66EG-S NV-HV61EC-S
NV-HV61EG-K NV-HV61EC-K
Ref.No. VEP06F51F VEP06F51F VEP06F51G
C7617 ECJ1VF1H103Z ECJ1VF1H103Z ECJ1VF1H103Z
C7618 - - ECJ1VB1C104K
C7623 ECJ2VF1C474Z ECJ2VF1C474Z F1J1C105A091
C7624 ECJ1VF1C474Z ECJ1VF1C474Z ECJ1VB1C104K
C7626 ECJ1VB1C104K ECJ1VB1C104K -
C7627 ECJ1VF1C474Z ECJ1VF1C474Z -
C7628 - - ECJ1VB1C104K
C7629 ECJ1VB1H123K ECJ1VB1H123K -
C7630 ECJ1VC1H681J ECJ1VC1H681J ERJ3GEYJ822V
C7632 ECJ1VB1H123K ECJ1VB1H123K -
C7633 ECJ1VC1H681J ECJ1VC1H681J -
C7636 ECJ1VF1C474Z ECJ1VF1C474Z -
C7637 ECJ1VB1H472K ECJ1VB1H472K -
F C7639
C7640
ECJ1VF1C474Z
ECJ1VB1H103K
ECJ1VF1C474Z
ECJ1VB1H103K
-
ECJ1VB1C104K
C7641 - - ECJ1VB1C104K
C7642 ECJ1VB1H103K ECJ1VB1H103K ECJ1VB1C104K
C7643 ECJ1VB1H152K ECJ1VB1H152K -
C7644 ECJ1VB1H152K ECJ1VB1H152K -
C7648 - - ECJ1VB1H103K
C7652 ECJ1VB1H152K ECJ1VB1H152K -
C7653 - - ECJ1VC1H100J
C7654 - - ECJ1VC1H100J
C7655 - - ECJ1VB1H102K
D7602 - - MA2C165001VT
DU7601 VEP07A71D VEP07A71D VEP07A71D
IC7602 C0ZBZ0000580 C0ZBZ0000580 C1AB00001404
K7617 ERJ6GEY0R00V ERJ6GEY0R00V -
K7618 - - ERJ6GEY0R00V
K7620 - - VWJ0023=5
K7621 - - ERJ6GEY0R00V
L7607 VWJ0023=5 VWJ0023=5 G0C2R2JA0019
L7608 VWJ0023=5 VWJ0023=5 G0C1R0JA0019
L7609 VWJ0023=5 VWJ0023=5 VWJ0023=5
LB7601 - - J0JCC0000080
LB7603 - - J0JCC0000124
E LB7604
LB7610
-
ERJ3GEY0R00V
-
ERJ3GEY0R00V
J0JCC0000124
J0JCC0000062
LB7611 ERJ3GEY0R00V ERJ3GEY0R00V J0JCC0000062
Q7601 2SD0601A0L 2SD0601A0L -
R4503 ERJ6GEYJ222V ERJ6GEYJ222V ERJ6GEYJ303V
R4504 ERJ6GEYJ222V ERJ6GEYJ222V ERJ6GEYJ303V
R4507 ERJ6GEYJ102V ERJ6GEYJ102V ERJ6GEYJ153V
R4510 ERJ6GEYJ102V ERJ6GEYJ102V ERJ6GEYJ153V
R7603 ERJ6GEY0R00V ERJ6GEY0R00V J0JCC0000124
R7610 ERJ6GEYJ683V ERJ6GEYJ683V -
R7621 ERJ6GEYJ392V ERJ6GEYJ392V ERJ6GEY0R00V
R7622 ERJ6GEYJ101V ERJ6GEYJ101V ERJ6GEY0R00V
R7623 ERJ6GEYJ472V ERJ6GEYJ472V ERJ6GEY0R00V
R7624 ERJ6GEYJ752V ERJ6GEYJ752V -
R7625 ERJ6GEYJ912V ERJ6GEYJ912V -
R7626 - - ERJ6GEY0R00V
R7627 ERJ6GEYJ562V ERJ6GEYJ562V -
R7628 - - ERJ6GEYJ103V
R7631 ERJ6GEYJ822V ERJ6GEYJ822V ERJ6GEYJ221V
R7632 ERJ6GEYJ822V ERJ6GEYJ822V ERJ6GEYJ221V
D R7637
TU7601
ERJ6GEYJ682V
ENG47327G1
ERJ6GEYJ682V
ENG47327G1
ERJ6GEYJ221V
ENG47327G1
X7601 H0H400400006 H0H400400006 H0D245500011
NV-HV61EB-S NV-HV61EBL-S NV-HV61EP-S NV-HV51EC-S
NV-HV61EB-K NV-HV61EP-K
Ref.No. VEP06F51H VEP06F51J VEP06F51L VEP06F51N
C7617 - ECJ1VF1H103Z ECJ1VF1H103Z ECJ1VF1H103Z
C7618 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7619 - ECJ1VB1C104K ECJ1VB1C104K -
C7623 F1J1C105A091 F1J1C105A091 F1J1C105A091 F1J1C105A091
C7624 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7628 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7630 ERJ3GEYJ822V ERJ3GEYJ822V ERJ3GEYJ822V ERJ3GEYJ822V
C7640 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7641 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7642 ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K ECJ1VB1C104K
C7648 ECJ1VB1H103K ECJ1VB1H103K ECJ1VB1H103K ECJ1VB1H103K
C C7653
C7654
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
ECJ1VC1H100J
C7655 ECJ1VB1H102K ECJ1VB1H102K ECJ1VB1H102K ECJ1VB1H102K
D7602 MA2C165001VT MA2C165001VT MA2C165001VT MA2C165001VT
DU7601 VEP07A71E VEP07A71F VEP07A71F VEP07A71D
IC7602 C1AB00001404 C1AB00001404 C1AB00001404 C1AB00001404
K7611 - ERJ6GEY0R00V ERJ6GEY0R00V -
K7613 - ERJ6GEY0R00V ERJ6GEY0R00V -
K7618 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
K7620 VWJ0023=5 VWJ0023=5 VWJ0023=5 VWJ0023=5
K7621 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
L7607 G0C2R2JA0019 G0C2R2JA0019 G0C2R2JA0019 G0C2R2JA0019
L7608 G0C1R0JA0019 G0C1R0JA0019 G0C1R0JA0019 G0C1R0JA0019
L7609 VWJ0023=5 VWJ0023=5 VWJ0023=5 VWJ0023=5
LB7601 J0JCC0000080 J0JCC0000080 J0JCC0000080 J0JCC0000080
LB7603 J0JCC0000124 J0JCC0000124 J0JCC0000124 J0JCC0000124
LB7604 J0JCC0000124 J0JCC0000124 J0JCC0000124 J0JCC0000124
LB7610 J0JCC0000062 J0JCC0000062 J0JCC0000062 J0JCC0000062
LB7611 J0JCC0000062 J0JCC0000062 J0JCC0000062 J0JCC0000062
R4503 ERJ6GEYJ303V ERJ6GEYJ303V ERJ6GEYJ303V ERJ6GEYJ303V
B R4504
R4507
ERJ6GEYJ303V
ERJ6GEYJ153V
ERJ6GEYJ303V
ERJ6GEYJ153V
ERJ6GEYJ303V
ERJ6GEYJ153V
ERJ6GEYJ303V
ERJ6GEYJ153V
R4510 ERJ6GEYJ153V ERJ6GEYJ153V ERJ6GEYJ153V ERJ6GEYJ153V
R7603 J0JCC0000124 J0JCC0000124 J0JCC0000124 J0JCC0000124
R7621 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
R7622 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
R7623 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
R7626 ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V ERJ6GEY0R00V
R7628 ERJ6GEYJ103V ERJ6GEYJ103V ERJ6GEYJ103V ERJ6GEYJ103V
R7631 ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V
R7632 ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V
R7637 ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V
TU7601 ENG47328G1 ENG47329G1 ENG47329G1 ENG47327G1
Note: X7601 H0D245500011 H0D245500011 H0D245500011 H0D245500011
Marked *(spare) parts are not assembled
NV-HV51EC
Important Safety Notice: !
NV-HV61EG/EC/EB/EBL/EP
A Components identified with the mark have NV-HV66EG
the special characteristics for safety.
When replacing any of these components MAIN PCB - AUDIO/RF/NICAM
use only the same type. SCHEMATIC DIAGRAM
1 2 3 4 5 6 7 8 9 10 11
