Image preview - the first page of the document
>> Download sh_sys documenatation <<
Text preview - extract from the document
VIDEO MAIN SIGNAL PATH IN REC MODE AUDIO MAIN SIGNAL PATH IN REC MODE NAVIGATION
VIDEO MAIN SIGNAL PATH IN PLAYBACK MODE AUDIO MAIN SIGNAL PATH IN PLAYBACK MODE INTERCONNECTION
MAIN PCB - TIMER
MAIN PCB - VIDEO I/O 1/2
MAIN PCB - VIDEO I/O 2/2
G MAIN PCB - AUDIO/RF/NICAM
F
{
UNREG_14V
E
MAIN PCB - TIMER MAIN PCB - POWER
UNREG_36V
CD
UNREG_6V
REF_GND
B
REF_GND
A
E
{
FIP (L)
b c d e f g
POWER KEY
NSW 5V
FLD CS
S CLK
S DATA
NV-HV61EG-S NV-HV66EG-S NV-HV61EC-S
NV-HV61EG-K NV-HV61EC-K
Ref.No. VEP06F51F VEP06F51F VEP06F51G
C6006 - - -
C6027 ECJ1VB1C333K ECJ1VB1C333K ECJ1VB1C333K
C6028 ECJ1VB1H222K ECJ1VB1H222K ECJ1VB1H222K
C6029 ECJ1VF1C474Z ECJ1VF1C474Z ECJ1VF1C474Z
C6030 ECJ1VC1H151J ECJ1VC1H151J ECJ1VC1H151J
C6031 ECJ1VF1C104Z ECJ1VF1C104Z ECJ1VF1C104Z
C6032 ECEA0JKA470B ECEA0JKA470B ECEA0JKA470B
IC6001 C2CBJG000349 C2CBJG000349 C2CBJG000349
D IC6003
K6005
C1AB00001293
VWJ0023=5
C1AB00001293
VWJ0023=5
C1AB00001293
VWJ0023=5
L6002 - - -
L6006 G0C680JA0019 G0C680JA0019 G0C680JA0019
Q6003 - - -
R6006 - - -
R6007 ERJ6GEYJ473V ERJ6GEYJ473V ERJ6GEYJ473V
R6051 ERJ6GEYJ564V ERJ6GEYJ564V ERJ6GEYJ564V
R6052 ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V
R6053 ERJ6GEYJ682V ERJ6GEYJ682V ERJ6GEYJ682V
R6054 ERJ6GEYJ125V ERJ6GEYJ125V ERJ6GEYJ125V
R6055 ERJ6GEYJ682V ERJ6GEYJ682V ERJ6GEYJ682V
R6056 ERJ6GEYJ125V ERJ6GEYJ125V ERJ6GEYJ125V
R6057 ERJ6GEYJ104V ERJ6GEYJ104V ERJ6GEYJ104V
R6058 ERJ6GEYJ222V ERJ6GEYJ222V ERJ6GEYJ222V
NV-HV61EB-S NV-HV61EBL-S NV-HV61EP-S NV-HV51EC-S
NV-HV61EB-K NV-HV61EP-K
Ref.No. VEP06F51H VEP06F51J VEP06F51L VEP06F51N
C6006 - - ECJ1VC1H330J -
C6027 ECJ1VB1C333K ECJ1VB1C333K ECJ1VB1C333K -
C6028 ECJ1VB1H222K ECJ1VB1H222K ECJ1VB1H222K -
C C6029
C6030
ECJ1VF1C474Z
ECJ1VC1H151J
ECJ1VF1C474Z
ECJ1VC1H151J
ECJ1VF1C474Z
ECJ1VC1H151J
-
-
C6031 ECJ1VF1C104Z ECJ1VF1C104Z ECJ1VF1C104Z -
C6032 ECEA0JKA470B ECEA0JKA470B ECEA0JKA470B -
IC6001 C2CBJG000362 C2CBJG000362 C2CBJG000362 C2CBJG000349
IC6003 C1AB00001293 C1AB00001293 C1AB00001293 -
K6005 VWJ0023=5 VWJ0023=5 VWJ0023=5 -
L6002 - - G0C330JA0019 -
L6006 G0C680JA0019 G0C680JA0019 G0C680JA0019 -
Q6003 - - 2SB0709A0L -
R6006 - - ERJ6GEYJ152V -
R6007 ERJ6GEYJ473V ERJ6GEYJ473V - ERJ6GEYJ473V
R6051 ERJ6GEYJ564V ERJ6GEYJ564V ERJ6GEYJ564V -
R6052 ERJ6GEYJ221V ERJ6GEYJ221V ERJ6GEYJ221V -
R6053 ERJ6GEYJ682V ERJ6GEYJ682V ERJ6GEYJ682V -
R6054 ERJ6GEYJ125V ERJ6GEYJ125V ERJ6GEYJ125V -
R6055 ERJ6GEYJ682V ERJ6GEYJ682V ERJ6GEYJ682V -
R6056 ERJ6GEYJ125V ERJ6GEYJ125V ERJ6GEYJ125V -
R6057 ERJ6GEYJ104V ERJ6GEYJ104V ERJ6GEYJ104V -
R6058 ERJ6GEYJ222V ERJ6GEYJ222V ERJ6GEYJ222V -
B
Note:
Marked *(spare) parts are not assembled
NV-HV51EC
Important Safety Notice: !
NV-HV61EG/EC/EB/EBL/EP
A Components identified with the mark have
NV-HV66EG
the special characteristics for safety.
When replacing any of these components MAIN PCB - SYSCON-SERVO
use only the same type. SCHEMATIC DIAGRAM
