TV DEMODULATOR PACK C.B.A.
(VEP07A23R) Transistor
Q0701 B-3
Q0702 A-3
Transistor & Resistor
D QR0707 C-4
Integrated Circuit
IC0701 C-2
Adjustment
T0701 B-3
VR0701 D-2
Connector
PK0701 A-2
PP0701 B-1
C ADDRESS INFORMATION
B
N
A
NV-SJ222EE-B
TV DEMODURATOR PACK C.B.A.
1 2 3 4
