T1150-3 STOP            T1150-5 STOP            T1150-7 STOP            T1150-14 STOP           T1150-16 STOP
190Vp-p (5msec.div.)    500Vp-p (5usec.div.)    36Vp-p (5usec.div.)     100Vp-p (5usec.div.)    1.8Vp-p (5usec.div.)




T1150-17 STOP           T1150-18 STOP           T1150-19 STOP           T1150-20 STOP           IC6001-13 PAUSE
2.2Vp-p (5usec.div.)    3.4Vp-p (5usec.div.)    5.2Vp-p (5usec.div.)    125Vp-p (5usec.div.)    4.4Vp-p (10msec.div.)




IC6001-18 REC           IC6001-52 REC           IC6001-70 REC           IC6001-68,69 REC        IC6001-79,80 FF/REW
4.4Vp-p (10msec.div.)   2.0Vp-p (10usec.div.)   4.6Vp-p (10msec.div.)   5.2Vp-p (10msec.div.)   5.0Vp-p (1msec.div.)




IC6001-71 REC           IC6001-72 REC           IC6001-94,95 REC        IC6001-97 PLAY          IC3001-73 REC/PLAY
4.8Vp-p (10msec.div.)   4.8Vp-p (10msec.div.)   6.0Vp-p (10msec.div.)   4.2Vp-p (10msec.div.)   4.8Vp-p (5msec.div.)




IC3001-74 REC/PLAY      IC4501-9,14 REC         IC4501-21 REC           IC4501-53,57 REC/PLAY
4.6Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)    1.2Vp-p (5msec.div.)
