Image preview - the first page of the document
>> Download Seagate Barracuda 180FC Installation guide documenatation <<
Text preview - extract from the document
2. Insert the drive
Slide the carrier or tray into the appropriate bay in your host system. This
connects the drive directly to your system's 40-pin Fibre Channel single
Barracuda 180FC Installation Guide connector attachment (FC-SCA). The FC-SCA connector is normally
Model ST1181677FC/FCV, Fibre Channel interface disc drive located on a Fibre Channel backpanel.
Publication Number: 100107697, Rev. A, August 2001 Note. There are no jumpers or terminators on the drive, and power is sup-
plied through the 40-pin connector.
