Image preview - the first page of the document
>> Download Seagate Barracuda 7200.9 PATA documenatation <<
Text preview - extract from the document
Attaching cables and mounting the drive
1. Attach one end of the drive interface cable to the interface connector on
your computer's motherboard (see your computer manual for connector
locations).
Note. When configuring two PATA devices on
Barracuda 7200.9 PATA Installation Guide the same cable, both must use Cable
ST3500841A, ST3500641A, ST3400833A, ST3400633A, ST3300822A, Master
Select or both must use Master/Slave
ST3300622A, ST3250824A, ST3250624A, ST3200827A, ST3160812A, jumper settings. If you are using a standard
Pin 1
40-pin cable, the master and slave
ST3160212A, ST3120814A, ST3120213A, ST3802110A, and ST3402111A Co
Mo mp
drives can be placed in any position. If you
Slave the uter
rbo
ard
are using a 40-pin 80-conductor cable, attach
Parallel ATA (PATA) Interface Disc Drives the blue connector to the motherboard,
the black connector to the master drive
Publication Number: 100389998, Rev. B, January 2006 and the grey connector to the slave drive.
What you need Caution. Align pin 1 on the motherboard connector with pin 1 on your drive
