Image preview - the first page of the document
Seagate Barracuda 7200.10 SATA


>> Download Seagate Barracuda 7200.10 SATA documenatation <<

Text preview - extract from the document
Product Manual




Barracuda 7200.10 Serial ATA




ST3750640AS      ST3250410AS
ST3750840AS      ST3250310AS
ST3500630AS      ST3200820AS
ST3500830AS      ST3160815AS
ST3400620AS      ST3160215AS
ST3400820AS      ST3120815AS
ST3320620AS      ST3120215AS
ST3320820AS      ST380815AS
ST3300620AS      ST380215AS
ST3300820AS      ST340815AS
ST3250620AS      ST340215AS
ST3250820AS




100402371
Rev. J
November 2007
                                         evision history

 Revision              Date          Sheets affected or comments
Rev. A                05/01/06       Initial release.
Rev. B                07/20/06       1, 3, 14-15, 26-28, 33, 35 and 49
Rev. C                08/14/06       10, 12, 14, 16, 19 and 27-28.
Rev. D                09/26/06       Added 160 - 40GB models
Rev. E                10/04/06       19, 21, 23, 25 and 35
Rev. F                05/04/07       Front cover, 1, 3, 14-15, 26-29, 33, 35, 38, 41-42, 49 and 53-56.
Rev. G                08/23/07       1.
Rev. H                09/06/07       4, 6, 8, 10, 12, 14-16, 27-28 and 35.
Rev. J                11/05/07       4, 6, 8, 10, 12, 14, 16, 18-25 and 27-29.
