Image preview - the first page of the document
>> Download Seagate Decathlon 850 documenatation <<
Text preview - extract from the document
decathlon 850
3.5
INCH FAMILY SLIM LINE
Fast ATA-2 Disc Drive
"Seagate's Decathlon 850 was hands down the fastest drive..." according to
PC/Computing. This 5,400-RPM disc drive can transfer data up to 16.6 Mbytes
per second with average seek times of 11 msec. Available 32-bit driver software
optimizes ATA drive performance on Microsoft Windows-based PCs.
Multimedia-ready with an average sustained data-transfer rate of
3.5 Mbytes per second. Ideal for graphic applications and full-screen,
full-motion MPEG video playback.
Designed for Windows 95 and easy installation. Printing the key settings right
on the mechanism prompted PC/Computing magazine to award
4 stars for usability.
Unique slim-line form-factor fits all standard 3.5-inch drive bays yet requires 35%
less space, reduces noise and can improve system cooling.
This Energy Ally drive has a very low power dissipation, making it possible to add
more peripherals by minimizing the load on the PC's power supply.
Manufactured to ISO 9001 standards, the Decathlon 850 disc drive has a 300,000
power-on-hour MTBF and is backed by a three-year warranty.
"Your choice in the less-than-1-Gbyte category." Editor's Choice Award
--PC/Computing, July 1995. Best Value for Budget Award
The Data Technology Company
decathlon 850
3.5
INCH FAMILY SLIM LINE
Fast ATA -2 Disc Drive
ST5850A
Decathlon
850
Drive Capacity
Formatted Mbytes (512 Bytes/Sector) 854.7
Interface
Fast ATA-2
Performance
Internal Transfer Rate, ZBR (Mbits/sec) 32.45 to 61.65
External Transfer Rate (Mbytes/sec) up to 16.6
Multisegmented Cache Buffer (Kbytes) 256
Track-to-Track Seek (msec) 3.5
Average Seek (msec) 11
Spindle Speed (RPM) 5,400
Average Latency (msec) 5.56
Configuration Organization
Discs/Read/Write Heads 2/4
Cylinders per Drive 4,085
Bytes per Sector 512
Recording Method RLL (1,7)
Logical Organization
Sectors per Track (max) 63
Read/Write Heads (max) 16
Cylinders (max) 1,656
Reliability and Data Integrity
MTBF (POH) 300,000
Service Life (years) 5
Nonrecoverable Read Errors per Bits Read 1 per 1013
Seek Errors per Physical Seeks 1 per 107
Auto-Park Yes
Limited Warranty (years) 3
Power Requirements
