Image preview - the first page of the document
>> Download RL9604S23096A documenatation <<Text preview - extract from the document Main Menu Table of Contents
Safety Indicator System
Brake Light Failure Sensor Test
'96 - 98 models: 5. Make sure the light in the safety indi-
cator comes on and goes off when the No. 7 terminal
1. First make sure the brake lights come on when the of the 8P connector is grounded, the brake pedal is
brake pedal is pressed. depressed, and the ignition switch is turned from OFF
to ON (II).
