Image preview - the first page of the document
>> Download 00AN_8A documenatation <<
Text preview - extract from the document
AN BATTERY 8A - 1
BATTERY
TABLE OF CONTENTS
page page
DESCRIPTION AND OPERATION REMOVAL AND INSTALLATION
BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 BATTERY HOLD DOWNS . . . . . . . . . . . . . . . . . . 18
BATTERY CABLES . . . . . . . . . . . . . . . . . . . . . . . . 3 BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
BATTERY HOLD DOWNS . . . . . . . . . . . . . . . . . . . 4 BATTERY TRAY. . . . . . . . . . . . . . . . . . . . . . . . . . 20
BATTERY TRAY. . . . . . . . . . . . . . . . . . . . . . . . . . . 4 CLEANING AND INSPECTION
DIAGNOSIS AND TESTING BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 SPECIFICATIONS
BATTERY CABLES . . . . . . . . . . . . . . . . . . . . . . . 14 BATTERY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SERVICE PROCEDURES
BATTERY CHARGING . . . . . . . . . . . . . . . . . . . . . 16
DESCRIPTION AND OPERATION material protrude from the top of the molded plastic
battery case to provide the means for connecting the
BATTERY battery to the vehicle electrical system. The battery
positive terminal post is visibly larger in diameter
DESCRIPTION than the negative terminal post, for easy identification.
The letters POS and NEG are also molded into the
top of the battery case adjacent to their respective
positive and negative terminal posts for additional
identification confirmation. Refer to Battery Cables
in the index of this service manual for the location of
more information on the battery cables that connect
the battery to the vehicle electrical system.
This battery is designed to provide a safe, efficient
and reliable means of storing electrical energy in a
chemical form. This means of energy storage allows
the battery to produce the electrical energy required
to operate the engine starting system, as well as to
operate many of the other vehicle accessory systems
for limited durations while the engine and/or the
charging system are not operating. The battery is
made up of six individual cells that are connected in
series. Each cell contains positively charged plate
groups that are connected with lead straps to the
positive terminal post, and negatively charged plate
Fig. 1 Maintenance-Free Battery - Typical
groups that are connected with lead straps to the
